Solidwings

SOLIDWINGS is meant for three shift application / medium intensity. Copper coated steel bead wire for firm fitment on rim & to avoid slippage during service.

Solidwings

Centre bar to avoid Lug damage.

SAFETY LINE mentioned on 60J rib which helps to plan tyre change without down time.

Rim guard available to protect rim flange.

Quick heel options available
Meant for two shift application

Comfort

Working hrs/day

Usage Intensity

Tyre Life

Solidwings Tyre Sizes

						Load capacity(kg)
			Tyre Dimension			Counter balanced lift truck upto 25 km/hr		Other Vehicles(Trailers)
Tyre Size	"Tyre Size (Metric Equivalent)"	RIM	O.D.(mm)	Section Width(mm)	"Wear Limit(60J) mm"	Load wheels	Steering wheels	Upto 6km/hr	Upto 10km/hr	Upto 25km/hr
4.00-8	-	3.00D-8	406	104	33	950	730	950	860	730
5.00-8	-	3.00D-8	452	110	36	1415	1090	1415	1285	1090
15x4 1/2-8	125/75-8	3.00D-8	377	118	30	1040	800	1040	945	800
16x6-8	150/75-8	4.33R-8	412	152	30	1495	1150	1495	1360	1150
18x7-8	180/70-8	4.33R-8	453	156	43	2145	1650	2145	1945	1650
6.00-9	-	4.00E-09	522	130	40	1885	1450	1885	1710	1450
21x8-9	200/75-9	6.00E-09	519	187	45	2755	2120	2755	2500	2120
140/55-9	-	4.00E-09	377	130	26	1170	900	1170	1060	900
200/50-10	-	6.5F-10	456	195	29.5	2470	1900	2470	2240	1900
6.50-10	-	5.00F-10	571	157	51	2340	1800	2340	2125	1800
6.50-10	-	5.50F-10	571	170	55.5	2340	1800	2340	2125	1800
23x9-10	225/75-10	6.50F-10	586	201	55	3445	2650	3445	3125	2650
23x10-12	250/60-12	8.00G-12	583	228	39	3770	2900	3770	3420	2900
7.00-12	-	5.00S-12	654	175	60	2920	2240	2920	2645	2240
27x10-12	250/75-12	8.00G-12	680	244	58	3900	3000	3900	3540	3000
5.50-15	`-	4.50E-15SDC	665	155	42	2145	1650	2145	1945	1650
7.00-15	-	5.50-15	729	179	55	3545	2725	3545	3215	2725
7.50-15	-	5.50-15	747	207	55	3900	3000	3900	3540	3000
7.50-15	-	6.00-15	747	207	55	3900	3000	3900	3540	3000
7.50-15	-	6.50-15	747	207	55	3900	3000	3900	3540	3000
8.15-15 (or) 28x9-15	225/75-15	7.00-15	689	215	47	3445	2650	3445	3125	2650
8.25-15	-	6.50-15	821	210	59	4750	3650	4750	4300	3650
250-15	250/70-15	7.00-15	726	210	53	4745	3650	4745	4300	3650
300-15	315/70-15	8.00-15	818	252	61	5850	4500	5850	5310	4500
28x12.5-15	355/45-15	9.75-15	690	286	50	5690	4375	5690	5165	4375
7.50-16	-	5.50-16	780	202	68	3965	3050	3965	3600	3050
7.50-16	-	6.00-16	780	202	68	3965	3050	3965	3600	3050
8.25-16	-	6.00-16	780	202	68	4750	3650	4750	4310	3650
9.00-20	-	6.50-20	997	229	77	5400	4500	5400	4905	4500
9.00-20	-	7.00-20	997	229	77	5400	4500	5400	4905	4500
10.00-20	-	7.50-20	1035	255	77	6000	5000	6000	5450	5000
10.00-20	-	8.00-20	1035	255	77	6000	5000	6000	5450	5000
11.00-20	-	7.50-20	1050	260	77	6540	5450	6540	5940	5450
11.00-20	-	8.00-20	1050	260	77	6540	5450	6540	5940	5450
